Air Wave Vari speed High Pressure 15Bar 15-22KW

Air Wave Vari speed High Pressure 15Bar 15-22KW

15-22 KW Options
15KW
22KW
Air Wave Vari speed High Pressure 15Bar 15-22KW

Airwave VARI-Speed 15-Bar Floor-Mounted Compressor Range
The Airwave VARI-Speed 15-Bar series delivers high-pressure industrial performance utilizing advanced Direct Drive Variable Speed Technology and oil-lubricated rotary screw pumps. Specifically engineered for heavy-duty commercial applications requiring higher working pressures, this 3-phase floor-mounted range eliminates integrated tank storage to provide high-volume, high-pressure air delivery within a standalone, space-saving footprint.
Key Features Across the Range
  • 15-Bar High-Pressure Performance: Specifically optimized to deliver variable, high-volume free air delivery (FAD) at elevated working pressures up to 15 bar.
  • Space-Saving Floor Mount: Zero integrated tank storage offers a compact, ultra-flexible layout designed to pipe directly into your high-pressure air receivers or distribution network.
  • Simple Installation: Engineered for a straightforward, hassle-free "Plug and Play" setup to maximize workshop uptime.
  • 100% Duty Factor: Heavy-duty architecture built for continuous, non-stop 3-phase industrial workloads under demanding pressures.
  • Advanced Smart Controls: Touchscreen monitoring panel complete with maintenance warnings, Wi-Fi connectivity, and a 7-day programmable start/stop function.
  • Premium Engineering: Oil-cooled permanent magnet motor, soft-start technology (low startup amps), and low component count solid seamless pipework.
  • Quiet & Efficient: Managed by an electric, thermostatically controlled cooling system to maintain optimal operating temperatures efficiently.
  • Configurable Air Treatment: Standalone design allows for modular integration. High-efficiency refrigerated dryers, -40°C desiccant dryers, and oil removal filters are available as optional extras.
  • Warranty: Backed by a 2-Year Warranty (T&Cs apply).
Available Models & Options

Option 1: Airwave VARI-Speed 20hp Floor Mounted 15-Bar [MK2] (Three Phase)
  • SKU: XL-20-EPM-EMC-15
  • Motor Power: 20 hp / 15 kW
  • Electrical Supply: 400V / 3 Phase / 50Hz
  • Air Output (FAD) @ 13 Bar: 36 – 62 CFM
  • Air Output (FAD) @ 15 Bar: 36 – 50 CFM
  • Tank Size: None (Floor Mounted)
  • Max Pressure: 15 Bar
  • Optional Add-ons: Floor Mounted Refrigerated Dryer (Model TR02), Oil Removal Filter, or Floor Mounted -40°C Desiccant Dryer (Model AWAC-ATK-APN 7)
  • Outlet Size: 3/4" BSP Female Thread
  • Noise Level: 65 dB(A)

Option 2: Airwave VARI-Speed 30hp Floor Mounted 15-Bar [MK2] (Three Phase)
  • SKU: XL-30-EPM-EMC-15
  • Motor Power: 30 hp / 22 kW
  • Electrical Supply: 400V / 3 Phase / 50Hz (63-amp)
  • Air Output (FAD) @ 10 Bar: 46 – 112 CFM
  • Air Output (FAD) @ 15 Bar: 46 – 77.5 CFM
  • Tank Size: None (Floor Mounted)
  • Max Pressure: 15 Bar
  • Optional Add-ons: Floor Mounted Refrigerated Dryer (Model TR03), Oil Removal Filter, or Floor Mounted -40°C Desiccant Dryer (Model AWAC-ATK-APN 11)
  • Outlet Size: 1" BSP Female Thread
  • Noise Level: 75 dB(A)
